1、上飾線切斷　2、下線切斷　3、抬壓腳裝置　4、直驅伺服電機



bs 500-d

電腦直驅高速大方頭自動減線繃縫機系列

bs 500-d

特點1：①一般車縫;
②一般針織品，運動衫、休閑服等。
特點2：
①本機型是高速小方頭繃縫機之基本機種，可加裝多種附件以適用于不同之作業(yè);
②新式針桿回油系統(tǒng)，絕無漏油疑慮。
③針桿傳動機構，采用密封式的設計，更安全與更易保持清潔;
④完備的自動供油系統(tǒng)與濾油裝置，確保**縫速可達6000針/分鐘;
⑤關鍵部件、過線、彎針采用進口零件，提高了機器的耐磨性和縫紉性能;
⑥自動化的配置，包括：背掛式迷你伺服馬達，氣動和電動式上/下自動切線裝置和抬壓腳裝置。操作簡易，
可大幅度提升縫紉品質和提高縫制效率;（氣動式的要配合空壓機使用）
⑦機體周長只有280mm,適用于領口及袖口等較小部位

bs 500-d

bs 500-d features:1)this machine is basic model of high-speed cylinder-bed interlock machine, can be equipped different accessories to suit for different work.
2)new type needle bar oil-back system, no possibility of oil leakage.
3)needle bar transmission structure, adopt all-sealed design, more safe and easier to keep clean.
4)complete automatic supply system and oil-filter device, ensure the max sewing speed to be 6000r.p.m.
5)some key parts are imported from japan, which enhance the wear-resistance of the machine.
6)automatic device including: back-hanging mini servo motor, pneumatic and electronic up/down automatic trimmer
device and foot lifter device. easy to operate, can improve the quality and efficiency of sewing work.
7)the circumference of sewing body is just 280mm, suitable for some small round parts such as collar and sleeve etc.
